A precast concrete column base assembly features a rectangular base plate secured by four anchor bolts arranged symmetrically around a structural steel column section. The dashed boundary outlines the base plate footprint with circular bolt holes positioned at each corner. Centerlines intersect at the midpoint of the column profile, establishing alignment for the structural connection.
