A heavy steel column and brace connection is anchored to a reinforced concrete footing. Dual diagonal braces connect via gusset plates welded to the column assembly with complete joint penetration welds. The base plate rests on a two-inch layer of non-shrink grout, explicitly omitting leveling nuts in favor of shim plates. Four massive anchor bolts pass through the footing, fitted with four-inch square by one-and-a-half-inch Grade 50 plate washers at the base, and wrapped with electrical tape along the top twelve inches to prevent bonding. A W14x257 shear key is embedded within a twenty-by-twenty-inch blockout in the footing to transfer lateral loads into the concrete foundation.
GUSSET PL PER CORE BRACE 2" NON-SHRINK GROUT 3" CLR TYP DO NUT USE LEVELING NUTS WHERE AT THESE BASE PLATE TYPES, USE SHIM PLATES (TYP) TYP (D.C.) CJP WF TO BASE PL DEPTH OF SHEAR KEY 1'-4" W14x257 SHEAR KEY BLOCK OUT 20x20 FOR SHEAR KEY T.O. FTG SEE PLAN FOOTING PER PLAN A CJP (D.C.) 45 DEG CJP TYP EA FLANGE (D.C.) 38 DEG 1'-0" REINF PER FTG SCHED SLAB ON GRADE TOP 12" OF ANCHOR BOLT W/ ELECTRICAL TAPE TO PREVENT BOND GRID 4"SQ x 1 1/2" PLATE WASHER (GR 50) TYP 3/8 B SECTION X-X PL TO EMBED TYP BRACE PER CORE BRACE BRACE PER CORE BRACE 6" MAX TYP
