Typical Depressed Structural Slab and Wall Opening Reinforcement Details

Elements

Beams Walls Floors / Slabs Reinforcing Roof / Floor Openings

Connections

About this detail

These details illustrate the reinforcement requirements for depressed structural slabs and wall openings. Typical wall reinforcement is maintained with a one-inch minimum clear cover, incorporating diagonal reinforcing bars at opening corners where required. Perimeter trim reinforcement surrounds the opening outline, with hooked bars used where continuous reinforcement is interrupted by penetrations. Slab reinforcement sizes match typical conditions, and bars bend to follow radiused slab edges.
