A continuous plate is welded to the top flange of the steel beam, with plate thickness sized relative to the beam flange thicknesses plus one-eighth inch. A five-eighths inch bar per drawing specifications is installed at the top flange location only. Shear tabs with bolted connections secure the beam web to the structural steel column flange. Fillet welds of five-sixteenths inch size connect components as specified by reference notes.
tf4 f3 5/8" BAR PER 8-S5.01 CONT. PLATE AT TOP FLANGE ONLY, t = (MAX. OF t & t ) + 1/8" OR LARGER IF REQUIRED BY IN THE PERPENDICULAR DIRECTION. SEE FOR WELDING TO COLUMN FLANGE f3 f4 t CL SYM. FOR NOTES 1 1/8" 1 1/16" 1 1/2" TO T.O. COLUMN, WHERE OCCURS. SEE FOR WELD 5/16 6 4 1 6
