An existing ten-inch steel beam frames into an interior wall assembly using connection angles on each side. A dowel extends through the wall on each side, anchored with epoxy filling the annular space. The first floor level marker indicates the vertical reference for the framing junction.
1ST FLR. CL SYM. CL SYM. DOWEL E.S. (E) 10" STL BEAM FILL ANULUS W/ EPOXY ANGLE E.S. 11
