Structural · S-BX3G8

Typical Concrete Coupling Beam Section and Reinforcement Detail

Elements

About this detail

A typical concrete coupling beam section includes top and bottom reinforcement, stirrups, and alternating consecutive crossties featuring ninety-degree hooks. Slab reinforcement is omitted from the view for clarity. Clear spacing dimensions comprise two and a half inches each side, one and a half inches top and bottom, and minimum clearances conforming to bar diameter or one inch. When the beam depth exceeds thirty-six inches, number four bars are added at a maximum of nine inches spaced evenly on each side.
