Bolt-hole pattern layout procedure for a braced frame connection between structural steel columns, beams, and diagonal bracing. The overall procedure requires establishing the uppermost bolt-hole at distance Lbh from the lower-most bolt-hole, and laying out the upper bolt-hole pattern similar to the lower pattern. Dimension Lwp-h need not be maintained at the top of the brace. Concrete blockout requirements and minimum bolt tensioning procedures are cross-referenced to specific secondary details.
CIRCLED NOTES ARE KEYED ON DETAIL. A LAYOUT BOTTOM BRACE CONNECTION OVERALL PROCEDURE: B ESTABLISH UPPER-MOST BOLT-HOLE, C LAYOUT UPPER BOLT-HOLE PATTERN FOR MINIMUM BOLT TENSIONING LOCATED AT DISTANCE L bh FROM SIMILAR TO LOWER BOLT-HOLE PATTERN. PROCEDURE SEE DETAIL 3/-. ON GUSSET. (SEE DETAIL 2/-) WP L bh L wp-h NOTE: DIM L wp-h NEED NOT BE MAINTAINED AT TOP OF BRACE B W wp H wp LOWER-MOST BOLT-HOLE. (SEE DETAIL 2/-) C A NOTE: SEE DETAIL 4/- WHERE CONCRETE BLOCKOUT WILL BE REQUIRED. D
