This connection detail joins a wide flange beam or channel to a hollow structural section column using a bolted framing connection and a cap plate at the top of the column. The beam web connects with bolts sized and numbered per plan through a connection plate welded with a one-quarter inch fillet weld. The top and bottom of the connection feature a field weld designated with a half-inch size marker.
WF BEAM OR CHANNEL TO J HSS COLUMN CONNECTION NO & SIZE OF BOLTS (SEE NOTE 3) HSS COLUMN WF BEAM OR CHANNEL (SEE PLAN) CAP PLATE AT TOP OF HSS COLUMN T&B 1/2" 1/4 M SHOWN ON PLAN THUS:
