Buckling-restrained braces frame into a steel column flange at a common work point with intersecting beams and stubs. Continuity plates are welded to the column flanges using complete joint penetration welds on three sides typically. Buckling-restrained braces are positioned per the elevation drawings where occurring, connecting back to gusset plates. Beam stubs connect to the framing per plan specifications, tied into the structural grid.
TYP TYP BRB PER ELEVATION BRB, WHERE OCCURS WP NOTES: 1. SEE DETAIL 1 FOR ADDITIONAL INFORMATION.. CJP 3 SIDES TYP CONTINUITY PL TYP BEAM STUB PER S-613 BEAM PER PLAN C L BEAM
