A chevron or diagonal bracing connection frames into the flange of a wide-flange column. Buckling-restrained braces connect through gusset plates positioned below the intersecting beam centerline. Complete joint penetration welds secure the continuity plates to the column web and flanges typically on three sides. Beam stubs and framing members connect per plan with typical fillet welds at intersecting joints.
TYP TYP BRB PER ELEVATION BRB, WHERE OCCURS WP NOTES: 1. SEE DETAIL 1 FOR ADDITIONAL INFORMATION.. CJP 3 SIDES TYP CONTINUITY PL TYP BEAM STUB PER S-613 BEAM PER PLAN C L BEAM C L COL NTS 3 BRACE TO COLUMN FLANGE - BRACES BELOW
