A canopy connection is formed by hollow structural section members framing into a bent plate with a closure plate as required. The bent plate measures 3/8 inches thick by 0 feet 10 inches high, featuring two 3/4 inch diameter by 0 feet 6 inch welded studs in one leg and two number 5 by 1 foot 6 inch long dowels in the other leg with full penetration welds typical. A three-sixteenths inch fillet weld secures the hollow structural section to the assembly, with framing sized per the framing plan.
