A concrete slab over steel deck bears on the top flange of a built-up wide flange beam. Shear studs are spaced per plan along the top flange of the beam. Structural angles measuring L4x3x1/4 with long legs vertical are connected typically to the top flange.
CONC SLAB OVER STL DECK BU WF BEAM TYP 3/4" TOP FLANGE > 3" TYP L4x3x1/4 LLV, TYP TOP FLANGE STUDS PER PLAN PER PLAN TOC 201 LEVEL ROOF 69' - 6"
