An HSS8x4x hollow structural section elevator separator tube frames into a supporting steel beam assembly with an L5x3 1/2"x3/8"x0'-4" angle welded with quarter-inch fillet welds. A continuous 3/16-inch bent plate is detailed at the elevator sill location, anchored by 1/2-inch diameter by 18-1/8-inch Nelson deformed bar anchors spaced at 12 inches on center. The structural connection is detailed in both elevation and section views adjacent to the elevator shaft opening.
ELEV104_12 NELSON DEFORMED BAR ANCHOR 1/2"øx18-1/8D2L @12"o.c. ELEVATOR SILL SEE ARCH'L BENT PL3/16 CONT. HSS8x4x ELEVATOR SEPARATOR TUBE SEE PLAN L5x3 1/2"x3/8x0'-4" (LLH) 1/4 1/4 4 1/4 3 4" 1/8 3-12 PLAN SEE SHAFT OPENING PLAN SEE 3 TYPICAL ELEVATOR SEPARATOR TUBE TO STEEL BEAM
