A glass fiber reinforced concrete roof connection featuring hollow structural section framing and welded plate assemblies. An HSS 5x5x5/16 tube spans vertically with a 3-inch diameter oversize hole and a three-eighths-inch thick stiffener plate welded to one face using typical quarter-inch fillet welds. An HSS 5x5x3/8 tube runs between verticals with a cover plate, tying into the structural steel beam below. A three-quarter-inch by twelve-inch square plate is welded to all intersected beams, supported by a three-eighths-inch stiffener plate at one face. The concrete slab is blocked out as required to accommodate the bearing joint and embed assembly provided by the GFRC fabricators.
4'-3" 3" DIA OVERSIZE HOLE 1/4" TYP 1/4 TYP . FOR TUBE SPACING, SEE S6.07 3/8" STIFFENER PLATE AT ONE FACE BLOCK OUT SLAB AS REQ'D ROOF BEARING JOINT AND EMBED BY GFRC FABRICATORS HSS5x5x5/16 TUBE SEE PLAN FOR LOCATIONS 3/4"x12" SQ. PLATE WELDED TO ALL INTERSECTED BEAMS HSS5x5x3/8 BETWEEN VERT. TYP. COVER PLATE
