A stabilizer plate measuring three-eighths by six inches by zero feet six inches with a thirteen-sixteenths inch diameter hole is welded to a wide flange column typically at joist locations. The plate is attached with a three-sixteenths inch fillet weld typical.
AT WF COL WELD PL3/8"x6"x COL WIDTH + 2" STABILIZER PL 3/8"x6"x0'-6" W/ 13/16"Ø HOLE TYP AT JST 3/16 TYP
