Diagonal bracing members framing into a structural gusset plate with threaded rods and angle sections. The assembly incorporates an L6x3-1/2x3/8 angle with long leg vertical positioned above an L3x3x1/4 framing angle, spaced with typical four-inch clearances. Threaded rods with nuts secure through the central connection plate while diagonal angles frame into the structural members beyond.
PLAN DETAIL "A" SEE PLAN CENTERLINE OF ROD AND L6x3 1/2x3/8 (LLV) ABOVE L3x3x1/4, FRAME TO L6x3 1/2x3/8 (LLV) BEYOND (TYPICAL) 4" (TYP.)
