S-BHD4N — Mechanical Opening Framing Plan at Wide Flange Beams

Structural · S-BHD4N

Mechanical Opening Framing Plan at Wide Flange Beams

Elements

About this detail

A wide flange girder spans across the top with wide flange beams framing into it and running parallel to form a structural bay. A mechanical opening is framed within the bay with one foot clearances indicated by structural dimensions and specified per plan. Bay spacing and member sizes are sized per plan.

S.A.D. 1'-0" S.A.D. 1'-0" BAY SPACING, SEE PLAN WF GIRDER, SEE PLAN WF BEAM, SEE PLAN CONDITION A WF BEAM, SEE PLAN MECH OPNG, S.A.D. FOR DIMENSIONS WF BEAM, SEE PLAN WF BEAM, SEE PLAN

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
