A precast concrete wall panel connects to the structure using a hot-dipped galvanized angle measuring L 8 x 4 x 1/2 by 1 foot 2 inches long. The angle is secured with two three-quarter-inch diameter Wej-It wedge anchors on each leg. Panel reinforcement is detailed per drawing 1.
