S-BFWNF — Concrete Pier Footing Reinforcement Layout

Structural · S-BFWNF

Concrete Pier Footing Reinforcement Layout

About this detail

Plan views of concrete pier footings PC4B, PC4C, and PC4D detail anchor bolt placement and reinforcing bar layouts relative to column centerlines. Footings PC4B and PC4D include number seven reinforcing bars at six inches each way. Dimensions establish length, width, and centerline offsets for each footing type.

CL COL, UNO PC4B & PC4D 3'-0" 3'-0" EQ EQ 2'-3" 2'-3" EQ EQ LENGTH WIDTH PC4C 5'-3" 2'-3" 2'-3" 2'-3" 1'-6" 2'-3" LENGTH CL COL, UNO WIDTH 2'-4" 2'-4" #7 @ 6" EW AT PC4D ONLY #7 @ 6" EW AT PC4D ONLY

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
