An insulated precast panel connects laterally for out-of-plane forces to a concrete slab on metal deck supported by a structural steel beam. A continuous bent plate measuring 1/2 inch by 6-1/2 inches anchors to the slab edge with 3/8-inch diameter by 3-foot long dowel bar anchors at 1 foot 0 inches on center maximum. The general contractor and precast subcontractor must coordinate locations to avoid conflicts with raised floor pedestals and provide a 3-inch horizontal slotted hole at each panel tieback. Continuous three number 5 chord reinforcing and continuous one number 3 bar with number 4 L-dowels at 12 inches on center maximum reinforce the slab edge. A 1-1/2 inch conduit penetration passes through the slab while leaving chord rebar uncut.
GRID TOSC EL REF PLAN CONCRETE SLAB ON METAL DECK REF PLAN STEEL BM REF PLAN 1/4 4-12 INSULATED PRECAST PANEL BY PRECASTER CONTINUOUS (3) - #5 CHORD REINF 3'-0" 4" #4 L-DOWEL @ 12" OC MAX W/ CONTINUOUS (1) - #3 GC TO COORDINATE GAP WITH PRECAST PANEL MFR PRECAST PANEL LATERAL (OUT-OF-PLANE) ONLY ATTACHMENT TO MAIN STRUCTURE BY PRECAST PANEL MFR CONT. BENT PL 1/2"x6 1/2"x AS REQUIRED W/ 3/8"Ø x 3'-0" LONG DOWEL BAR ANCHOR @ 1'-0"o.c. MAX. (GC / PRECAST SUB TO LOCATE CONNECTIONS TO NOT TO CONFLICT WITH RAISED FLOOR PEDESTALS) 1 1/2" CONDUIT PENETRATION DO NOT CUT CHORD REBAR REF PLAN PANEL ATTACHMENT PLATE BY PRECASTER. PROVIDE 3" HORIZ SLOTTED HOLE AT EA PANEL TIEBACK. GC TO COORDINATE WITH PRECASTER 1"
