Four structural steel angles of size 3x3x1/4 are arranged diagonally around a wide-flange steel column to provide support for steel deck where required. The connection utilizes typical three-sixteenths-inch fillet welds as specified. The angles are positioned symmetrically to frame into the column web and flanges.
