Standard dimensions and geometric tolerances for structural rivets per ASTM F 1667, showing head dimensions, shank diameters, penetration depth P, and total length L. Edge distance is specified as 1/2 inch minimum and spacing as 1 inch minimum.
0.345" +/- 0.01" 0.25" +/- 0.01" 0.125" MIN. 0.125" 0.25" PENETRATION = P RIVET LENGTH = L 0.25" +/- 0.03" 0.125" +/- 0.005" 0.25" +/- 0.01" MIN es = 1/2" MIN. sp = 1" RIVET DIMENSIONS RIVET DIMENSIONS ARE TAKEN FROM ASTM F 1667.
