An exit sign features a dark gray body and white symbols with a maximum one-quarter-inch projection from the wall surface. The lettering consists of uppercase characters with a minimum height of five-eighths of an inch and is raised one-thirty-second of an inch in compliance with California Building Code section 11B-703.2. Lettering colors contrast with the background field per CBC 11B-703.3.1. Signage installation heights range from forty inches minimum to sixty inches maximum to the centerline of the sign per note four.
DARK GRAY 60" MAX. * EXIT TO EXIT EXIT ROUTE 40" MAX. * WHITE SYMBOL MIN. 5/8" UPPER CASE LETTER. RAISED 1/32" PER CBC 11B-703.2 LETTERING IN CONTRASTING COLOR FROM FIELD PER CBC 11B-703.3.1 EXIT SIGN D 1/4" MAX. SEE NOTE #4 4"
