A guardrail replacement is installed in an existing sleeve typical at a ramp. Spalled concrete corner repairs are coordinated per adjacent sheet references.
6 5 5 CONDITION 2 GUARDRAIL REPLACEMENT IN EXIST SLEEVVE TYPICAL AT RAMP, SEE 8/S-401 SPALLED CORNER REPAIR PER 6/S-401
