A continuous 7x4x3/8 inch bent plate connects to an existing 10-inch concrete masonry unit wall using half-inch diameter Hilti HIT-HY 70 adhesive anchors spaced at four feet on center. Anchors require four and a half inches of effective embedment at solid grouted masonry and two inches with a short screen tube at hollow masonry. The metal deck bears on the bent plate and connects with vertical short slotted holes, finger-tight nuts, and staked threads to accommodate differential movement. Deck welding follows sheet reference 1/S5.31.
GRID (E) 10" CMU WALL - FIELD VERIFY CONT. 7x4x3/8 BENT / LLV - PROVIDE VERT. SHORT SLOTTED HOLES - FINGER TIGHT NUTS AND STAKE THREADS MTL DECK - FOR WELDING SEE 1 S5.31 1/2"6 HILTI HIT-HY 70 @ 4'-0" O.C. - PROVIDE 4½" EFFECTIVE EMBEDMENT AT SOLID GROUTED CMU - PROVIDE SHORT SCREEN TUBE W/ 2" EFFECTIVE EMBEDMENT AT HOLLOW CMU
