A CoreBrace buckling-restrained brace connects to a gusset plate slotted to receive the brace tongue, welded with five-sixteenths fillet welds. The gusset plate is attached to a structural steel beam sized per plan and features a one-half-inch stiffener plate on near side and far side of the gusset. Concrete over steel deck abuts the gusset connection at the floor level. Gusset and attachment design is provided by CoreBrace.
Wb Lwb Wb Lwb TYP TYP WORK POINT COREBRACE BRB TYP 5/16 5/16 TYP GUSSET AND ATTACHMENT DESIGN BY COREBRACE TYP SLOT GUSSET TO RECEIVE BRB TYP CONC OVER STL DECK STL BM SEE PLAN STIFF PL 1/2" NS & FS OF GUSSET Wb Lwb Wb Lwb Lgb Lgc
