This structural detail shows a steel column connected via base plate BP11, measuring ten inches by five inches with typical two-inch clearances. The assembly incorporates four anchor bolts symmetrically arranged around the structural steel shape. A note directs the user to see sheet 8 for additional information not noted on this view.
3 E NOTE: SEE FOR INFO. NOT NOTED 8 - 2" TYP. 10" 10" 5" 5" BP11 DETAIL
