Two structural steel roof trusses meet at a ridge slope break with a complete joint penetration weld specified at the top chord intersection. Internal truss seat connections are provided where required to transfer loads across the joint. The connection detail shows two typical configurations designated as A and B.
A B TRUSS SEAT WHERE OCCURS TRUSS SEAT WHERE OCCURS CJP CJP TRUSS SEAT WHERE OCCURS
