A wood beam bears against a quarter-inch thick steel end plate welded to the steel beam web with a quarter-inch fillet weld. The wood beam is bolted to the steel end plate using three-quarter-inch diameter machine bolts. Six bolts are specified for members eleven and seven-eighths inches or deeper, while four bolts are used for nine-and-a-half-inch deep members.
C L CL A: SECTION 3" 3" 1 1/2" 3" MIN . A A 1/4" THICK END PLATE WOOD BEAM BOLTED TO STEEL END PLATE w/: (6) 3/4" ∅ M.B. FOR 11 7/8" OR DEEPER BM (4) 3/4" ∅ M.B. FOR 9 1/2" DEEP BM 1/4
