The steel column splice is aligned along the centerline and features finished column ends for full bearing. A plate is attached to each side of the column web or uses a welded web connection as an alternate per contractor option. Field welds are specified at each flange and along the web plates.
EACH FLANGE PLATE EACH SIDE OF COLUMN WEB OR WELD COLUMN WEBS FINISH COLUMN ENDS FOR FULL BEARING (TYP) PER CONTRACTOR OPTION RE: NOTE 8 ALTERNATE WELDED WEB IN LIEU OF WEB PLATE CL COLUMN A WELDED
