An HSS 6x6x1/4 ladder column supports an open web steel joist carrying a metal roof deck. Diagonal angle braces of L3x3x1/4 size intersect the assembly, with two L3x3x1/4 angles placed on each side. Welds are specified as three-sixteenths inch fillet welds on three sides where indicated, while the column is left unwelded to the angle.
MTL ROOF DECK HSS6x6x1/4 LADDER COL L3x3x1/4", EA SIDE OPEN WEB STL JST (2) L3x3x1/4 ANGLE BRACE L3x3x1/4 DO NOT WELD COL TO ANGLE 3/16 3/16 3/16 (3) SIDES
