A mechanical unit weighing two thousand five hundred pounds or less is suspended from a structural steel joist and metal roof deck assembly using hanging rods coordinated with the mechanical contractor. Two L5x3x1/4 angles are provided, with Unistrut specified for units weighing less than 300 pounds. Typical L6x4x5/16 angles measuring zero feet ten inches long are welded with three-sixteenth-inch fillet welds. Five-and-a-half-inch by three-inch spacer plates one-sixteenth inch thicker than the hanging rods are placed at the third points. All welds are specified as one-quarter-inch fillet welds typical.
MECH UNIT, SEE MECH DWGS (2) L5x3x1/4 (LLV) USE UNISTRUT FOR UNITS WEIGHING LESS THAN 300# L6x4x5/16 x 0'-10" (LLV) TYP HANGING RODS, SEE MECH CONTRACTOR 5 1/2"x3" SPACER PL 1/16" THICKER THAN HANGING RODS AT THIRD POINTS TYP 1/4 1/4 1/4 3/16 STL JST MTL ROOF DECK (FOR UNITS WEIGHING 2500#'S OR LESS)
