A structural steel column connects to a base plate with a complete-joint-penetration doubler plate welded at the base. A gusset plate with a ninety-degree orientation is welded to the base plate and supports a diagonal member encased in casing. The diagonal member connects to the gusset plate through a multi-bolt shear connection. Additional weld symbols and dimensional variables designate the plate lengths, widths, and edge distances.
L gc APPROX COL 4 W.P. @ TOP OF BASE PLATE L gb APPROX 6 SEE W b BASE PLATE 90° 6 SEE W c L wc L wb 9 SEE e L bh L wp-h (BOT. ONLY) CASING 1" MIN W L C.J.P DOUBLER TO BASE PLATE
