A concrete masonry unit wall runs parallel to an overhead steel roof deck, featuring top channel bracing and a bond beam. A C5x6.7 channel at 8 inches or a C5x9 channel at 12 inches is placed on each side of the masonry wall with an 8-foot maximum span, welded with quarter-inch fillet welds. The masonry extends at least one course above the channels. A compressible fire-rated filler seals the gap between the top of the wall and the underside of the steel roof deck or wide-flange beam.
1 1/2" EXTEND (1) COURSE MIN ABOVE CHANNELS TYP AT C5 3 3 1/4 1/4 C5x6.7 AT 8" CMU, C5x9 AT 12" CMU, EA SIDE OF CMU, 8'-0" MAX SPAN ROOF DECK ROOF JST OR WF BEAM COMPRESSIBLE FILLER, FIRE RATED AS REQD WALL PARALLEL TO STEEL ROOF DECK 4 1/4" BOND BEAM NOTES: 1. SEE "TYPICAL CMU NON-LOAD BEARING WALL OPENING AROUND INCOMING BEAM". TYP TOW GAP
