A braced frame beam connects to a column using a gusset plate sized per the structural drawings. The beam member connects via a three-eighths-inch minimum plate with three erection bolts as required. Complete joint penetration welds secure the web and top and bottom flanges to the plate. A thirty degree plus or minus ten degree angle requirement governs the geometry, maintaining specified one-inch and two-inch minimum clearances.
BM PER "BRACED FRAME EL" DC, CJP WEB TO PL DC, CJP T&B GUSSET PL PL PER "TYP BF-COL FLG CONDITION" OR "TYP BF-COL WEB CONDITION", T&B (3) SIDES N PL3/8 MIN 3" ERECTION BOLTS AS REQD 1" MIN 2" MIN 30° ± 10° 1" MIN WELDED CONNECTION
