Wide-flange beams frame into a wide-flange column utilizing web connection plates sized per plan. Column stiffener plates are welded to each side of the column web with five-sixteenths-inch fillet welds, with plate thickness equal to the larger of the connecting beam flange thicknesses. Beam top and bottom flanges are welded to the column flanges with complete-joint-penetration groove welds. A one-and-a-half-inch typical clearance is maintained at the beam-to-column interface.
T/SLAB PER PLAN d t f2 f1 C COL L TYP T&B FLANGE 5/16 5/16 TYP s WF COL PER PLAN STIFF 'S EA SIDE ts = t OR t WHICHEVER IS GREATER f1 f2 1 1/2" TYP CONN PER 7/S7.1.01 WF BEAM PER PLAN t t SECTION tf1/2 OR tf2/2 WHICHEVER IS GREATER TYP
