A one-half inch thick bent plate or angle frames the edge of the composite steel deck and concrete slab at the column flange. An L3x3x5/16 angle provides deck support below, welded with a quarter-inch fillet weld. Five-sixteenth inch fillet welds with five-inch spacing connect the structural members. The deck span runs perpendicular to the edge condition.
1/2" THICK BENT PLATE OR ANGLE 5" TYPICAL EDGE OF SLAB SEE TYPICAL COMPOSITE STEEL DECK AT SLAB EDGE L3X3X5/16 DECK SUPPORT SEE NOTE 4 OR SEE ALTERNATE DECK SPAN 5/16 5 5/16 5 1/4 B DETAIL AT EDGE COLUMN
