A twelve gauge minimum metal curb sits atop concrete over metal deck supported by a wide-flange beam or channel sized per plan. The curb is anchored to the concrete slab using half-inch diameter by two-inch embedment Hilti KB-TZ expansion anchors located at each corner and spaced at a maximum of eighteen inches on center along each side. A closure plate is installed as detailed per plan at the deck edge. A minimum eight-inch high level curb with cant and flashing is provided by the general contractor.
CURB ATTACHMENT__ Wx BEAM PER PLAN OR CHANNEL PER CURB 12 GA. MIN. ATTACH CURB TO SLAB W/ 1/2"Øx2" EMBED HILTI KB-TZ AT EA. CORNER and 18" O/C MAX. EA. SIDE CLOSURE PL. PER CONC. OVER METAL DECK PER PLAN 6A 5 S0.22 5 S0.22 MIN. 3" 6A - MIN. 8" HIGH LEVEL CURB W/ CANT and FLASHING BY G.C. A TYP. 7 HANGER CONN. FOR SUSPENDED EQUIPMENT AT BARE METAL DECK AND ALTERNATE PIPING, CABLE TRAY and DUCT SUPPORT FRAMING
