This structural framing assembly supports roof drains using L3x3x1/4 angle frame members spanning between steel beams sized per plans. Connections are welded with three-sixteenths-inch fillet welds typical at the framing junctions. Option B permits trimming the vertical leg at the joist, and short angle segments measuring L3x3x1/4 by zero-feet-six-inches are provided as a contractor option where applicable.
OPEN OPEN OPEN OPEN TRIM VERTICAL LEG AT JOIST 3/16 TYP 3/16 STEEL BEAM, SEE PLANS A A A A 3/16 TYP 3/16 TYP TYP 3/16 3/16 TYP 3/16 3/16 ANGLE FRAME L3x3x1/4, TYP ANGLE FRAME L3x3x1/4, TYP L3x3x1/4 x 0'-6" TYP. CONTRACTOR MAY L3x3x1/4 x 0'-6" TYP. CONTRACTOR MAY USE OPTION B IF DESIRED OPTION B SECTION A-A 2
