A five-eighths inch plate is welded to the underside of a structural steel beam flange with a one-quarter inch fillet weld. Four seven-eighths inch diameter A325 bolts connect the plate to the member below. A note indicates that no hollow structural section is present at the similar condition, and connection information refers to sheet 16/S-605 for typical unnoted conditions.
SECT GRID PL5/8 1/2" MIN (4) 7/8"ø A325 BOLTS TYP 1/4 SEE FOR CONN INFO, TYP UNO 16/S-605 NO HSS AT SIM SECTION 1/2" 2" 6" 2" TYP 1 1/2" TYP 1 1/2"
