Cold-formed steel stud framing assembly featuring a box header and sill connection to a jamb member. The connection is secured with four number ten sheet metal screws fastened through the clip track flange at the track joint. Vertical studs tie into the track with wall sheathing or drywall applied to the exterior face.
1 TRACK 3 CLIP TRACK FLANGE AT TRACK JOINT 2 (4) #10 S.M.S. 4 STUD 5 WALL SHEATHING OR DRYWALL 1 2 3 4 5 1" = 1'-0" S1.9 5 TYP BOX HEADER & SILL CONNECTION TO JAMB
