A structural beam brace connects to a concrete-filled steel deck assembly using a three-eighths-inch by ten-inch ASTM A36 plate welded with three-sixteenths-inch fillet welds on near and far sides. The connection incorporates a half-inch by sixteen-inch plate equipped with four three-quarter-inch diameter studs engaging two deck flutes. The brace aligns perpendicular or parallel to the deck, maintaining a maximum two-inch offset.
BRACE PARALLEL TO DECK NS & FS 3/16 WP CONC ON STL DECK PL1/2x16 W/ (4) 3/4"ø STUDS,ENGAGE (2) DECK FLUTES CONN PER "TYP BM BRACE" DET MAX 2" 2 MIN 1 PL3/8x10 (A36) BRACE PERPENDICULAR TO DECK TYP 6" 2" TYP 13 TYPICAL BEAM BRACE TO STEEL DECK
