Structural · S-AQ6GA

Typical BRBF Column Base Plate Detail - Web

Materials

Steel

Elements

Columns Bracing Anchors / Embeds Connections / Plates

Connections

Braced Frame Connection Gusset Plate Base Plate / Anchorage Bracing Connection Welded Connection Embed Plate

About this detail

A buckling-restrained braced frame column base plate connection viewed at the column web. The base plate features typical anchor rods per schedule, along with two additional 1 1/2-inch diameter Grade 55 anchor rods required where the number of gusset plate anchor rods exceeds twice the number of plate anchor rods. A gusset plate connects to the column web via complete joint penetration welds, with fillet welds specified typically at five-sixteenths of an inch. Additional requirements mandate consulting the braced frame base connection schedule and manufacturer-approved shop drawings for final plate thicknesses, lengths, and weld sizes.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
