A structural steel davit anchor assembly mounts to a primary support beam per plan using a galvanized 2-inch thick, 1'-4" by 1'-4" anchor base plate and an HSS 7.625x0.328 galvanized davit base. The base plate is welded with five-sixteenths inch fillet welds on three sides, and beam stiffeners are provided on both sides centered under the plate edge. A perpendicular W12x26 minimum beam connects alongside, supported by a one-half inch near side and far side plate matching the beam width. The connection is designed to resist gravity and davit up and down loads of twenty-five kips minimum.
A - CL BEAM CL ANCHOR CL PERPENDICULAR BEAM CL ANCHOR MIN 7" MIN 8" MIN 8" W12X26 MINIMUM PERPENDICULAR BEAM OR AS INDICATED ON DRAWINGS NEAREST ADJACENT BEAM PER PLAN 2 1/4" ANCHOR BASE PLATE PRIMARY SUPPORT BEAM PER PLAN CONNECTION PER 9/S5.203. SEE PLAN FOR BEAM SHEAR EACH END DUE TO GRAVITY AND DAVIT UP / DOWN (U/D) LOADS (25 KIPS MINIMUM). DECK SPAN SEE NOTE 1 MIN 8" B PLAN A SECTION PL 1/2 NS/FS MATCH BM WIDTH TYP 5/16 5/16 (3) SIDES, TYP BM STIFFENER BOTH SIDES CENTERED UNDER PLATE EDGE. TYP (6) LOCS PER DAVIT. SEE SEC A FOR SIZE AND WELD MAX 1/2" NOTE: SEE LOADING DIAGRAMS FOR MAXIMUM BASIS OF DESIGN DAVIT LOADS. PL2"x1'-4"x1'-4" GALVANIZED W/ HOLES COORDINATED W/ MANUF REQUIREMENTS 6" COORD W/ ARCH & MANUF 1'-6" MAX HSS7.625x0.328 GALVANIZED DAVIT BASE BY OTHERS MIN 1' - 0" 5/16 5/16 CJP SCALE: NOT TO SCALE 3 DAVIT ANCHOR CONNECTION DETAIL ON BEAM
