Structural · S-APQKY

Stair Tower Parapet Steel Framing and Kicker Detail

Materials

Steel Timber / Wood

Elements

Beams Walls Stairs Roofs Parapets Arches Bracing Insulation

Connections

Bracing Connection

About this detail

A structural detail at a stair tower parapet wall and roof junction features a steel beam supporting the roof decking, specified per plan and schedule, which connects to vertical steel stud framing. A diagonal kicker brace ties back to the adjacent roof beam to provide lateral support, with member sizing coordinated per the structural plans. Two number twelve screws spaced at sixteen inches on center fasten the assembly through the roof decking into the underlying steel beam. Insulation and exterior finish are coordinated with the architectural drawings.
