A concrete slab-on-grade rests against a concrete foundation wall supported by a concrete footing. Vertical wall reinforcing extends from the footing into the wall with continuous reinforcing at the top and bottom. The cold joint between the foundation wall and the slab haunch requires a roughened surface to one-quarter inch amplitude. The exterior wall system above is coordinated with architectural drawings.
SB502-B1 CONCRETE WALL HORIZ WALL REINF CONCRETE FOOTING ROUGHEN SURFACE TO 1/4" AMPLITUDE VERT WALL REINF CONT REINF TOP & BOT CONC. SLAB ON GRADE EXTERIOR SLAB OR GRADE EXTERIOR WALL SYSTEM SEE ARCH SB501 D4
