An A572 Grade 50 steel base plate measuring four feet by two feet six inches supports a hollow structural section column that receives gusset plates slotted through the column profile. Four stiffener plates match the three-quarter-inch minimum thickness of the gusset plates, which are provided by the buckling-restrained braced frame supplier. A twenty-five-inch by five-inch by thirty-inch long shear lug projects from the bottom side of the base plate. Anchor bolts are installed per the structural schedule around the perimeter.
10" 4" 1'-10" 4" 2'-6" 10" 10" 4'-0" 5" 5" 5" 5" 2 1/2" x 5" x 30" LONG SHEAR LUG (BOTTOM SIDE OF PLATE) A572 Gr 50 STEEL BASE PL SLOT GUSSET PL THRU COLUMN, SEE DETAILS 8" ANCHOR BOLTS PER SCHEDULE 6" GUSSET PL BY BRB SUPPLIER STIFFENER PLATE (4) LOCATIONS. THICKNESS TO MATCH GUSSET PLATE (3/4" MIN) 10" 4" 4"
