An elevator guide rail is mounted to a hollow structural section support using three-quarter-inch diameter through bolts centered in two-inch long vertical slotted holes. The structural support consists of a hollow structural section per plan with angles on each side welded with five-sixteenth-inch fillet welds spaced at four inches typical. A wide-flange beam with a three-eighths-inch full-height stiffener plate intersects the assembly, braced by a kicker member.
CONDITION AT BREAK-IN HSS 5/16 4 TYP EA ANGLE GUIDE RAIL PER MANUFACTURER 3/4"Ø THRU BOLT CENTERED IN 2" LONG VERT SLOTTED HOLE HSS PER PLAN L6x1/2x3/8 (LLV) EA SIDE OF HSS Wx PER PLAN 3" KICKER PER 9/S6.02 3/8" FULL HEIGHT STIFFENER PLATE 1"
