Concrete wall corners and intersections incorporate horizontal lap splices and vertical reinforcing bars typically specified as four number five bars for double mats and two number five bars for single mats unless otherwise noted. Ninety degree hooks are detailed at corners, though straight corner bars may be used in lieu of bent bars. Alternate bends are applied typically at wall intersections to maintain proper rebar spacing and continuity.
CORNER INTERSECTION INTERSECTION CORNER SINGLE MAT DOUBLE MAT (4) #5 VERT TYP UNO CORNER BAR MAY BE USED IN LIEU OF BEND 90° HOOK TYP (2) #5 VERT TYP UNO ALTERNATE BENDS TYP SPLICE HORIZ LAP SPLICE HORIZ LAP SPLICE HORIZ LAP SPLICE HORIZ LAP
