Level 3 connection featuring wide flange beams with bolted web connections and a vertical structural member aligning with grid line F. A thermal bracket connects the framing assemblies with a designated two-inch clearance. Additional connection details are referenced on sheets S5.02 and S7.03.
LVL 3 F CONNECTION PER 4 S5.02 5 S7.03 5██████████ 5██████████ 5███████████████ ██████████5 ██████████5 ██████████5 ██████████5 WF BM WF BM 2" FOR DETAILS & CALLOUTS IN COMMON SEE 1 S7.03
